SS 310 Welded Pipe, Stainless Steel 310 UNS S31000 Seamless Pipes & Tubes
Original Photograph Of Stainless Steel 304 Pipe & Tube At Our Warehouse, Mumbai
Specification
- Specifications –ASTM A/ASME SA213/A249/A269/A312/A358 CL. I to V ASTM A789/A790
- Size – Seamless 310 Pipes & Tubes – 1/2″ NB – 24″ NB
- ERW 310 Pipes & Tubes – 1/2″ NB – 24″ NB
- EFW 310 Pipes & Tubes – 6″ NB – 100″ NB
- Wall Thickness – Schedule 5S – Schedule XXS.
| Dimensions | : | ASTM, ASME and API |
| Schedule | : | SCH 10, SCH20, SCH30, SCH40, STD, SCH60, XS, SCH80, SCH120, SCH140, SCH160, XXS |
| Type | : | Seamless / ERW / Welded / Fabricated / LSAW Pipes |
| Length | : | Single Random, Double Random & Cut Length. |
| Form | : | Round, Square, Rectangular, Hydraulic Etc. |
Composition ranges for stainless steel 310 grade
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 310 | min.max. | –0.25 | –2.00 | –1.50 | –0.045 | –0.030 | 24.026.0 | – | 19.022.0 | – |
Mechanical properties of stainless steel 310 grade
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 310 | 515 | 205 | 40 | 95 | 217 |
Physical properties of stainless steel 310 grade in the annealed condition
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (m/m/°C) | Thermal Conductivity(W/m.K) | Specific Heat 0-100°C (J/kg.K) | Electrical Resistivity (n.m) | |||
| 0-100°C | 0-315°C | 0-538°C | at 100°C | at 500°C | |||||
| 310 | 7750 | 200 | 15.9 | 16.2 | 17.0 | 14.2 | 18.7 | 500 | 720 |
Specifications for stainless steel 310 grade
| Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | ||
| BS | En | No | Name | ||||
| 310 | S310009 | 310S24 | – | 1.4840 | X15CrNi25-20 | – | SUH 310 |
